Materials: SUS302, 304, 304L, 316, 316L stainless steel wire brass wire, iron wire, low-carbon steel wire.
Characteristics: Stainless steel wire mesh is heating-resisting, acid-resisting, wear resisting, corrosion-resistant.
Uses: Used in oil, chemical industry, chemical fibre, rubber tire products medicine, food products and so on.
Art.No. SJDCWM-
Art.No. SJDCWM-
Art.No. SJDCWM-
| No. | Mesh/Inch (warp×weft) | Diameter (warp×weft) | Aperture (mm) | Weight/Square Meter (kg) |
|---|---|---|---|---|
| 32# | 8×62 | 0.63mm×0.45mm | 300 | 5.42 |
| 40# | 10×79 | 0.50mm×0.355mm | 250 | 3.16 |
| 48# | 12×64 | 0.58mm×0.40mm | 280 | 2.90 |
| 55# | 14×88 | 0.40mm×0.30mm | 180 | 2.54 |
| 76# | 19×140 | 0.315mm×0.20mm | 140 | 1.88 |
| 80# | 20×300 | 0.35mm×0.20mm | - | 3.60 |
| 95# | 24×110 | 0.355mm×0.25mm | 120 | 2.45 |
| 100# | 25×140 | 0.28mm×0.20mm | 100 | 1.95 |
| 120# | 30×150 | 0.25mm×0.18mm | 80 | 1.68 |
| 140# | 35×175 | 0.224mm×0.16mm | 71 | 1.52 |
| 160# | 40×200 | 0.20mm×0.14mm | 60 | 1.40 |
| 180# | 45×250 | 0.16mm×0.112mm | 56 | 1.09 |
| 200# | 50×250 | 0.14mm×0.11mm | 53 | 1.04 |
| 220# | 55.5×280 | 0.14mm×0.10mm | 50 | 0.92 |
| 240# | 65×330 | 0.11mm×0.08mm | 36 | 0.71 |
| 280#(1) | 70×350 | 0.11mm×0.08mm | 35 | 0.72 |
| 280#(2) | 78×385 | 0.11mm×0.07mm | 32 | 0.75 |
| 300# | 78×700 | 0.11mm×0.08mm | 30 | 1.39 |
| 315#(1) | 80×400 | 0.10mm×0.065mm | 40 | 0.62 |
| 315#(2) | 80×600 | 0.10mm×0.06mm | - | - |
| 315#(3) | 80×800 | 0.10mm×0.04mm | - | - |
| 320# | 81×780 | 0.10mm×0.07mm | 30 | 1.22 |
| 354# | 90×550 | 0.12mm×0.05mm | - | - |
| Roll Width: 1m-1.6m | ||||
| No. | Mesh/Inch (warp*weft) | Diameter (warp*weft) | Aperture (mm) | Weight/Square Meter (kg) |
|---|---|---|---|---|
| 360# | 91×787 | 0.10mm×0.07mm | 25 | 1.24 |
| 400# | 101×900 | 0.10mm×0.063mm | 20 | 1.22 |
| 472# | 120×400 | 0.10mm×0.075mm | - | - |
| 500# | 127×1100 | 0.07mm×0.05mm | 17 | 0.81 |
| 630# | 160×1500 | 0.063mm×0.04mm | 15 | 0.62 |
| 650#(1) | 165×400 | 0.71mm×0.06mm | - | - |
| 650#(2) | 165×600 | 0.71mm×0.05mm | - | - |
| 650#(3) | 165×800 | 0.71mm×0.05mm | 25 | - |
| 650#(4) | 165×1100 | 0.71mm×0.045mm | - | - |
| 650#(5) | 165×1400 | 0.71mm×0.4mm | 16 | 0.76 |
| 685# | 174×1700 | 0.063mm×0.032mm | 13 | 0.61 |
| 787#(1) | 200×600 | 0.70mm×0.06mm | - | - |
| 787#(2) | 200×800 | 0.71mm×0.05mm | - | - |
| 787#(3) | 200×1760 | 0.71mm×0.04mm | 12 | 0.8 |
| 795# | 202×1760 | 0.05mm×0.032mm | 10 | 0.6 |
| 850# | 216×1860 | 0.045mm×0.030mm | 9 | - |
| 1000# | 254×2000 | 0.04mm×0.028mm | 8 | 0.5 |
| 1125# | 285×2235 | 0.036mm×0.025mm | 7 | - |
| 1228# | 312×2100 | 0.035mm×0.025mm | - | - |
| 1250# | 318×2235 | 0.036mm×0.025mm | - | - |
| 1280# | 325×2300 | 0.035mm×0.025mm | 5 | 0.45 |
| 1575# | 400×3100 | 0.035mm×0.019mm | 3 | - |
| Roll Width: 1m-1.6m | ||||
