Material: SUS/ AISI, 201, 202, 302, 304, 304L, 430, 316, 316L, 310S, 321 etc.
Size: 0.025 - 5.5mm.
Kinds: Hard wire, stainless steel wire, bright wire, soft wire.
Uses: Stainless steel wire is used in a number of industries including wire-drawing, weaving of wire mesh, soft pipe, steel wire rope, filter material and equipment, spring, making of handicrafts, etc.
Art.No. SJSSW-
Art.No. SJSSW-
Art.No. SJSSW-
Art.No. SJSSW-
Art.No. SJSSW-
Art.No. SJSSW-
| Wire Diameter(mm) | Tolerance(mm) | Max. Deviation Tolerance (mm) |
| 0.020-0.049 | +0.002/-0.001 | 0.001 |
| 0.050-0.074 | 0.002 | 0.002 |
| 0.075-0.089 | 0.002 | 0.002 |
| 0.090-0.109 | +0.003/-0.002 | 0.002 |
| 0.110-0.169 | 0.003 | 0.003 |
| 0.170-0.184 | 0.004 | 0.004 |
| 0.185-0.199 | 0.004 | 0.004 |
| 0.200-0.299 | 0.005 | 0.005 |
| 0.300-0.310 | 0.006 | 0.006 |
| 0.320-0.499 | 0.006 | 0.006 |
| AISI Grade |
Chemical Composition(%) | ||||||
| C | Si | Mn | P | S | Ni | Mo | |
| 304 | =<0.08 | =<1.00 | =<2.00 | =<0.045 | =<0.030 | 8.00~10.50 | - |
| 304H | > 0.08 | =<1.00 | =<2.00 | =<0.045 | =<0.030 | 8.00~10.50 | - |
| 304L | =<0.030 | =<1.00 | =<2.00 | =<0.045 | =<0.030 | 9.00~13.50 | - |
| 316 | =<0.045 | =<1.00 | =<2.00 | =<0.045 | =<0.030 | 10.00~14.00 | 2.00~3.00 |
| 316L | =<0.030 | =<1.00 | =<2.00 | =<0.045 | =<0.030 | 12.00~15.00 | 2.00~3.00 |
| 430 | =<0.12 | =<0.75 | =<1.00 | =<0.040 | =<0.030 | =<0.60 | - |
| 430A | =<0.06 | =<0.50 | =<0.50 | =<0.030 | =<0.50 | =<0.25 | - |
